Medical Applications

LNL-77E-4761-3

ES Electronic Rotary Latch - Compact

• Striker to be ordered separately. (LNL-77E-24STRK or LNL-77E-29STRK)
• Integrated mechanical release (2 locations).
• Universal thru hole mounting.

• Voltage: 12V.
• Max Current Draw: 3A.

• Tensile Load: 200 lbs.
• Striker Diameter Size: .12"
• Response Time: 30mS (DC12V).
• Operation: Pulse.
• Does not meet FMVSS 206 standards.

• Hook/Catch: A3 cold steel.
• Lock Strike: Stainless steel.
• Case: Black electro-coated steel.

• Operating Temperature Range: -20 degrees Celsius to 80 degrees Celsius.
• Humidity: 95%

• Bare wire, single stage.

• RoHS, UL.

LNL-77E-5873-93

ES Electronic Rotary Latch - Medium

• Striker to be ordered separately. (LNL-77E-24STRK or LNL-77E-29STRK)
• Integrated mechanical release (2 locations).
• Universal thru hole mounting.
• Integral spring push rod (option).
• Internal sensor - closed position (option).

• Voltage: 12V.
• Max Current Draw: 3A.

• Tensile Load: 500 lbs.
• Striker Diameter Size: .12"
• Response Time: 30mS (DC12V).
• Operation: Pulse.
• Does not meet FMVSS 206 standards.

• Hook/Catch: A3 cold steel.
• Lock Strike: Stainless steel.
• Case: Black electro-coated steel.

• Operating Temperature Range: -20 degrees Celsius to 80 degrees Celsius.
• Humidity: 95%

• Bare wire, internal switch - closed position, integrated spring plunger, single stage.

• RoHS, UL.

LNL-77E-6772-93

ES Electronic Rotary Latch - Large

• Striker to be ordered separately. (LNL-77E-24STRK or LNL-77E-29STRK)
• Integrated mechanical release (2 locations).
• Universal thru hole mounting.
• Integral spring push rod (option).
• Internal sensor - closed position (option).

• Voltage: 12V.
• Max Current Draw: 3A.

• Tensile Load: 600 lbs.
• Striker Diameter Size: .12"
• Response Time: 30mS (DC12V).
• Operation: Pulse.
• Does not meet FMVSS 206 standards.

• Hook/Catch: A3 cold steel.
• Lock Strike: Stainless steel.
• Case: Black electro-coated steel.

• Operating Temperature Range: -20 degrees Celsius to 80 degrees Celsius.
• Humidity: 95%

• Bare wire, internal switch, - closed position, integrated spring plunger, single stage.

• RoHS, UL.

S201A

Switch Lock, Off-On Position with Spring Return, 1.6875

Economical Switch Lock, 1.6875" with Spring Return, Solder Post, Off-On Position.

V3171CH6

Indoor 20 amp Key Switch Lock, 2.4375in

Indoor 20 amp Key Switch Lock with screw type terminals, 2.4375".

V3272CH6

IP66 Rated 20 amp Outdoor Key Switch Lock, 2.75"

Outdoor IP66 rated 20 amp switch lock, resistant to moisture, dust, salt and extreme temperatures, 2.75".
