Quarter Turns
Additional Product Information
Specifications | Inches | part No | Rotation | Milimeters | Spring Return | Key Code | Market | Water Resistance | Tumbler Count | Length |
|---|---|---|---|---|---|---|---|---|---|
| 1-1/8 | DTL170L | 90° Knob Turn, 180° Key Turn | 28.6 | N/A | N/A | Outdoor, Automotive | Yes | N/A | 1.125 |
Specifications
- Non-locking 1/4 turn solution.
- Easy operation using thumb and finger.
- Various cams, rotations and finishes.
- Suitable for outdoor use.
- Ball and spring detent standard.
- Internal O-ring available.
- DTL170 Series
Material and Finish
- Housing: Zinc Alloy.
- Finish: Bright Chrome US26 (Standard).
- Satin Nickel US15.
- Black E-Coat (Optional).
- Outdoor rated chrome plated over double nickel.
Overview
Cam Rotation & Installation
Cam Types
Accessories/Replacement Parts
Cam Screw 1/4-28
PN: S23032G
Nut Lock
PN: S9003A
Barrel Nut M19
PN: D9868
Spur Washer
PN: S2302A
Spur Washer
PN: S2302B
Anchor Washer
PN: S6951
Flat Washer
PN: S2313
Speed-Clip
PN: HS6397
Metal Finger Pull
PN: FP333
