LNL-77E-6772-93

ES Electronic Rotary Latch - Large

link

  • Striker to be ordered separately. (LNL-77E-24STRK or LNL-77E-29STRK)
  • Integrated mechanical release (2 locations).
  • Universal thru hole mounting.
  • Integral spring push rod (option).
  • Internal sensor - closed position (option).

Power Specifications
  • Voltage: 12V.
  • Max Current Draw: 3A.
Actuation Specifications
  • Tensile Load: 600 lbs.
  • Striker Diameter Size: .12"
  • Response Time: 30mS (DC12V).
  • Operation: Pulse.
  • Does not meet FMVSS 206 standards.
Material Specifications
  • Hook/Catch: A3 cold steel.
  • Lock Strike: Stainless steel.
  • Case: Black electro-coated steel.
Environmental Specifications
  • Operating Temperature Range: -20 degrees Celsius to 80 degrees Celsius.
  • Humidity: 95%
Options
  • Bare wire, internal switch, - closed position, integrated spring plunger, single stage.
Certifications
  • RoHS, UL.
product image
product image

Additional Product Information

Download 2D Drawing
